Agriculture Irrigation Smooth Holding Tank With Superior Corrosion Resistance Capability

Agriculture Irrigation Smooth Holding Tank With Superior Corrosion Resistance Capability
Agriculture Irrigation Smooth Holding Tank With Superior Corrosion Resistance Capability

Large Image :  Agriculture Irrigation Smooth Holding Tank With Superior Corrosion Resistance Capability

Product Details:
Place of Origin: CHINA
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20180508006
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: $5000~$20000 ONE SET
Packaging Details: PE poly-foam between each two steel plates;wooden pallet and wooden box
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 SETS PER MONTH
Detailed Product Description
Coating Color: Dark Blue, Dark Green , White, And Customized A Standard Steel Plate Size: Effective Size 2400mm X 1200 M
Steel Plates Thickness: 3mm - 12mm , Depends On The Diameter & Height Coating Thickness: 0.25mm - 0.4mm, Two Coating Internal And External
Easy Yo Clean: Smooth, Glossy, Inert, Anti-adhesion
High Light:

sludge holding tanks

,

sewage storage tank

Sludge Storage Tank Designed according to AWWA D-103/09 with Superior Corrosion Resistance Capability



Sludge holding tanks are needed at some of municipal and industrial waste water treatment plants . Even farmers need sludge storage tank . Depending on what kind of sludge the tank is holding , Ph value of the sludge varies . To store sludge , the tank would better be very smooth so that dust and hardened sludge can be cleared easily . It is important that the sludge tank looks elegant especially the whole plant is built at a factory or community. When the sludge could be corrosive , the capability of corrosion resistance will be the utmost characteristics needed . Last but not least , if the sludge tank can be erected with un-skilled workers at shortest time , this will be a excellent choice of sludge storage tank .

Where can you get such a sludge storage tank ? Here you are . Center Enamel Co., Ltd is the leader manufacturer of glass lined steel bolted tanks in China . Glass lined steel bolted tank is smooth and glossy , free from graffiti ; be able to make customized color ; superior at corrosion resistant ; fast at installation; need minimum maintenance during lifetime. Center Enamel Co., ltd have been installed glass lined steel bolted tanks at over 30 countries .



Why use glass lined steel tank other than others ?

Think about these advantages :

* superior performance in corrosion resistance and against rust

*factory fabrication tank . No painting or spray on erection site .

* minimal maintenance cost

* No need crane or other large equipment during erection

* not subjected to severe weather and environment.

* can be designed to future expansion, dismantle or re-movement.

* free service for technical drawings

* turn key service from proposal to tank commissioning .



Technical date of glass lined steel tank

Coating color dark blue, dark green , white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm , depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coating internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet , around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds





Application



Water supply and water treatment



Waste water treatment

Sewage and effluent treatment



Power and energy



Industrial bulk storage



Agriculture irrigation system





Fire protection system



Fire protection system
